Stator R7-1.5
Description
Stator R7-1.5
Stator for R7-1.5 (R7-1,5) Screw Pump
Made in Germany
The R7-1.5 Stator, also known as R7-1,5, is a premium-quality stator designed for use with the R7-1.5 progressive cavity pump (rotor stator pump). Manufactured in Germany, it delivers reliable conveying performance, stable pressure build-up, and long service life for demanding mortar, screed, grout, concrete, and industrial pumping applications.
With a diameter of 114.3 mm and a length of 270 mm, the stator is designed for use with the matching R7-1.5 rotor. The 73 Shore rubber compound provides excellent sealing, reliable pumping performance, and high wear resistance when conveying abrasive materials with a maximum grain size of 7 mm.
At 400 / 200 RPM, the stator delivers an approximate flow rate of 60 / 30 l/min, making it ideal for a wide range of construction material pumping applications.
R7-1.5 Stator Versions
The standard R7-1.5 stator features external grooves, requiring an external clamp during operation.
The stator is also available in the following versions:
- Maintenance-free version (without grooves)
- Integrated clamp version
The standard stator is supplied in brown.
If you require a different stator version, please contact us. We will be happy to recommend the correct configuration for your machine.
For optimum pumping performance, pressure build-up, and maximum service life, we recommend purchasing the complete R7-1.5 Rotor Stator Set.
Key Features
- Made in Germany
- Stator for R7-1.5 (R7-1,5) screw pump
- Stator diameter: 114.3 mm
- Stator length: 270 mm
- Rubber quality: 73 Shore
- Flow rate (@ 400 / 200 RPM): 60 / 30 l/min
- Maximum grain size: 7 mm
- Standard version with grooves
- Maintenance-free version available
- Integrated clamp version available
- Standard colour: Brown
- Compatible with R7-1.5 rotor
Benefits
- Reliable conveying performance
- Stable pressure build-up
- Excellent sealing between rotor and stator
- High wear resistance
- Long service life
- Available in multiple versions for different machine configurations
- Precision-manufactured for dependable operation
Applications
Suitable for:
- Progressive cavity pumps
- Mortar pumps
- Concrete pumps
- Screed pumps
- Grout pumps
- Construction machinery
- Material conveying systems
Technical Information
- Product Type: Stator
- Pump Size: R7-1.5 (R7-1,5)
- Diameter: 114.3 mm
- Length: 270 mm
- Rubber Quality: 73 Shore
- Flow Rate (@ 400 / 200 RPM): 60 / 30 l/min
- Maximum Grain Size: 7 mm
- Standard Version: Grooved (requires external clamp)
- Alternative Versions: Maintenance-free or integrated clamp
- Standard Colour: Brown
- Compatible Rotor: R7-1.5 Rotor
- Country of Origin: Germany
